Available Now■ Functional Features - Applies to commercial, residential applications for on-grid and off-grid applications. - Produced with strict quality control standards and a worldwide certification program. - Easily installed on the ground, roof, building face or tracking system. - Reduces electricity cost and creates energy independently. - Modular, no moving parts, fully scalable and easily installed. - Reliable and virtually maintenance-free power generation. - Helps environment by reducing air, water and land pollution. - Provides clean, quiet and reliable electricity generation.
| Specification | Value |
|---|---|
| Max. System Voltage | 600V DC / 1000V DC |
| Temperature Cycling Range | -40℃ to +85℃ |
| NOCT | 47℃ |
| Temperature Coefficient of Isc | +0.06% /℃ |
| Temperature Coefficient of Voc | -0.35% /℃ |
| Temperature Coefficient of Pmax | -0.4% /℃ |
Typical Electrical Characteristics
| Model | XH20P (36) | XH40P (36) | XH50P (36) | XH60P (36) | XH90P (36) | XH100P (36) |
|---|---|---|---|---|---|---|
| Max Power (Pmax) | 20 Wp | 40 Wp | 50 Wp | 60 Wp | 90 Wp | 100 Wp |
| Module Dimension (mm) | 539×366×25 | 650×506×25 | 784×506×35 | 768×664×35 | 998×664×35 | 1131×664×35 |
| Optimum Operating Voltage (Vm) | 17.3 V | 17.3 V | 17.5 V | 17.3 V | 17.6 V | 17.4 V |
| Optimum Operating Current (Im) | 1.16 A | 2.32 A | 2.85 A | 3.47 A | 5.12 A | 5.75 A |
| Open-circuit Voltage (Voc) | 21.7 V | 21.7 V | 21.8 V | 21.7 V | 21.8 V | 21.7 V |
| Short-circuit Current (Isc) | 1.26 A | 2.53 A | 3.15 A | 3.93 A | 5.58 A | 6.31 A |
| Weight | 2.1 kg | 4 kg | 4.8 kg | 6.2 kg | 8.2 kg | 9 kg |
| Max Series Fuse Rating | 2 A | 5 A | 6 A | 7 A | 8 A | 8 A |
