Available Now■ Functional Features - Applies to commercial, residential applications for on-grid and off-grid applications. - Produced with strict quality control standards and a worldwide certification program. - Easily installed on the ground, roof, building face or tracking system. - Reduces electricity cost and creates energy independently. - Modular, no moving parts, fully scalable and easily installed. - Reliable and virtually maintenance-free power generation. - Helps environment by reducing air, water and land pollution. - Provides clean, quiet and reliable electricity generation.
| Specification | 36×5 Mono Series | 36×6 Mono Series |
|---|---|---|
| Solar Cell Type | Mono-crystalline | Mono-crystalline |
| Cell Size | 125×125 mm | 156×156 mm |
| Power Tolerance (Pmax) | 0 to +3% | 0 to +3% |
| Number of Cells | 36 pcs in series | 36 pcs in series |
| Module Dimension | 1201×545×35 mm | 1488×664×35 mm |
| Weight | 8 kg | 12 kg |
| Max System Voltage | 1000V DC | 1000V DC |
| Max Series Fuse Rating | 10A | 10A |
| Temperature Cycling Range | -40℃ to +85℃ | -40℃ to +85℃ |
| NOCT | 47℃ | 47℃ |
| Temperature Coefficient of Isc | +0.06% /℃ | +0.06% /℃ |
| Temperature Coefficient of Voc | -0.35% /℃ | -0.35% /℃ |
| Temperature Coefficient of Pmax | -0.4% /℃ | -0.4% /℃ |
| Load Capacity (20' GP) | 648 pcs | 392 pcs |
| Load Capacity (40' GP) | 1368 pcs | — |
| Load Capacity (40' HQ) | — | 840 pcs |
